Epson
TM-U675

Description

Compact Multifunction POS Printer with MICR. This easy-to-use POS printer sports superior slip handling and printing speeds that satisfy the most demanding customer requirements. The accurate MICR reader bundled with fast check handling and printing speed is a perfect match for the retail and banking environment.

KEY FEATURES:

  • High-speed MICR reading and check printing
  • Quietest printer in its class
  • Easy drop-in paper loading and one touch removal
  • Wider throat for smooth drop-in validation
  • Superior slip handling with built-in forms stopper
  • Optimized features and small footprint perfect for busy counters

Specifications

Print Method: 9-pin, serial impact dot matrix
Print Font: 5 x 9 / 7 x 9
Print Speed: Approx. 5.14 lps (40 columns, 17.8 cpi)
Paper Dimensions: Receipt or Journal: 82.5 + 0.5 x diameter 83mm

Slip: 70 to 148 x 150 to 210mm

Validation: 148 to 150 x 70 to 210 mm

Paper Thickness: Receipts or Journal: 0.06 to 0.085 mm

Slip: 0.09 to 0.2 mm / sheet

Validation: 8 lines
Copy Capability: One original and two copies
Inked Ribbon: ERC-32 (purple)
Ribbon Life: 6,000,000 characters
Power Supply Voltage: 24 VDC + 10%
Current Consumption: Approximately 1.7 A (mean)
D.K. D. Function: 2 drivers
Reliability: MTBF 180,000 hours

MCBF 37,000,000 lines

Overall Dimensions (W/D/H): 186 x 298 x 195 mm
Mass: Approximately 4.8kg

With autocutter 5.8kg

EMI Standards: VCCI class A, FCC class A, CE marking
Safety Standards: UL, CSA
Interfaces: RS-232C/Bi-directional parallel/RS-485/USB/Connect-IT
Factory Options: Autocutter, MICR
Data Buffer: 4 KB or 45 bytes
NV Bit Image Memory: 384 KB can be used to store graphic files

Documents

Product Broshure
