Magner
75UM

Call for Price

Description

Magner  75 UM Currency Counter offers the technology, performance, and productivity you expect from MAGNER® — the global leader in table-top currency counters. With a wide range of features and options, the 75 Series is designed for accurate highspeed processing, simplicity of operation, and rugged reliability, even in the most demanding applications.

KEY FEATURES:

  • High volume vault grade counter
  • 600, 1200, 1500 notes per minute (selectable)
  •  500 Note Hopper
  •  150 Note Stacker
  • Ultraviolet Detection
  • Dual-head, Dual Threshold, Magnetic Counterfeit Detection

Specifications

Specifications
Counting Speed: 600, 1200, 1500 notes per minute (selectable)
Display Type: LCD 3 digit batch display
4 digit count display
Document Size Limits: 1.97″ x 3.54″ to 3.94″ x 7.28″
50 mm x 90 mm to 100 mm x 185 mm
Hopper Capacity: 500 circulated notes
Stacker Capacity: 150 circulated notes
Batching: Variable 1 to 999
Error Detection: Double, chain, half-note, jam, hopper jam, short count, open door, note in stacker
Counterfeit Detection: Dual-head, dual threshold magnetic detection
Ultraviolet detection
Document Feed Mechanism: Friction, intermittent roller type
Dimensions: 10.04″ (H) x 11.02″ (W) x 9.06′ (D)
255 mm (H) x 280 mm (W) x 230 mm(D)
Net Weight: 15.50 lbs. (7.03 kg.)
Power Source: 120V 60Hz/230V 50Hz
Power Consumption: 70W (average)
Operating Temperature Limits: +32° F to +104° F (0° C to 40° C)
Density Setting: Adjustable, 5 levels
Connection: RS232 interface

Documents

Product Brochure
