Magner
75UM
Call for Price
Description
Magner 75 UM Currency Counter offers the technology, performance, and productivity you expect from MAGNER® — the global leader in table-top currency counters. With a wide range of features and options, the 75 Series is designed for accurate highspeed processing, simplicity of operation, and rugged reliability, even in the most demanding applications.
KEY FEATURES:
- High volume vault grade counter
- 600, 1200, 1500 notes per minute (selectable)
- 500 Note Hopper
- 150 Note Stacker
- Ultraviolet Detection
- Dual-head, Dual Threshold, Magnetic Counterfeit Detection
Specifications
| Specifications | |
| Counting Speed: | 600, 1200, 1500 notes per minute (selectable) |
| Display Type: | LCD 3 digit batch display 4 digit count display |
| Document Size Limits: | 1.97″ x 3.54″ to 3.94″ x 7.28″ 50 mm x 90 mm to 100 mm x 185 mm |
| Hopper Capacity: | 500 circulated notes |
| Stacker Capacity: | 150 circulated notes |
| Batching: | Variable 1 to 999 |
| Error Detection: | Double, chain, half-note, jam, hopper jam, short count, open door, note in stacker |
| Counterfeit Detection: | Dual-head, dual threshold magnetic detection Ultraviolet detection |
| Document Feed Mechanism: | Friction, intermittent roller type |
| Dimensions: | 10.04″ (H) x 11.02″ (W) x 9.06′ (D) 255 mm (H) x 280 mm (W) x 230 mm(D) |
| Net Weight: | 15.50 lbs. (7.03 kg.) |
| Power Source: | 120V 60Hz/230V 50Hz |
| Power Consumption: | 70W (average) |
| Operating Temperature Limits: | +32° F to +104° F (0° C to 40° C) |
| Density Setting: | Adjustable, 5 levels |
| Connection: | RS232 interface |
Product Brochure
